Static electricity

Figure 1. A child on a playground is seen to have experienced static electricity due to contact with the slide.[1]

Static electricity is the imbalance of electric charge on a surface of a material. Static means fixed or stationary, therefore it is used in contrast to dynamic (moving) electricity which are in the form of electric currents.

Typically atoms are neutral, which means they have the same number of electrons and protons. However atoms become charged when there is an imbalance in the amounts of these particles, which can happen fairly easily for certain materials. The ability for a material to hold on to its electrons determines its place in the "triboelectric series".[2] The farther two materials are ranked in this series, the more noticeable the charge separation is when they come in contact. For example glass and silk are relatively far apart in this series, so when glass is rubbed with silk it will lose many electrons to the silk, and static electricity can be observed.[2]

Charging

Figure 2. Charge-induced separation.[3]

Charge separation of two objects can be induced in several different ways.

  • Contact-induced separation is accomplished by rubbing two objects together, since objects in contact form a chemical bond known as adhesion. Adhesion is the tendency for different surfaces to cling to one another. Friction is often assumed to be the cause of this static charging, but friction is actually caused by adhesion and shockingly has no influence on charge separation.[4]
  • Heat and Pressure-induced separation occurs when certain types of crystals or ceramics have a stress applied to them, or are heated.
  • Charge-induced separation occurs when a charged object is brought close to a neutral one. The charges inside of the neutral object of the same polarity as the charged object will be repelled while charges of the opposite polarity will be attracted to it. This causes the once neutral object to have an imbalance of charge. This can be seen in Figure 2.

Discharging

Figure 3. Lightning is the discharge of static build-up in thunder clouds.[5]

Once an object has built up a charge imbalance, it will naturally want to become neutral once again. This happens by what is called discharging, which can commonly be felt by a shock when it happens to a person. Contact-induced charging is the most commonly experienced form of static electricity build up, as can be accomplished by rubbing ones feet on the carpet. Once enough charge is built up, there is a high enough voltage needed to cause the charge to jump from the person to a nearby doorknob leaving the person discharged and, if they weren't ready for it, quite shocked.

This same charge build-up and discharge process occurs in clouds to create lightning, and can be explored on Hyperphysics.


PhET Simulation

The University of Colorado has graciously allowed us to use the following PhET simulation. This simulation shows how charges get separated (but are neither created nor destroyed) when a balloon rubs on a person's sweater.

For Further Reading

For further information please see the related pages below:
